ASUS TUF GAMING X870-PLUS WIFI (90MB1IU0-M0EAY0)

Motherboard - ATX - Socket AM5 - AMD X870 Chipset

USB4, USB-C 3.2 Gen 2x2, USB 3.2 Gen 2, USB 3.2 Gen 1 - Wi-Fi 7, 2.5 Gigabit LAN, Bluetooth - Onboard Graphics (CPU Required) - HD Audio (8-channel)

Overview

The ASUS TUF GAMING X870-PLUS WIFI motherboard offers a platform for building a powerful and durable gaming rig. Equipped with a Socket AM5 interface, it supports Ryzen 7000, 8000, and 9000 Series processors. It offers up to 192 GB of DDR5 memory across four DIMM slots, supports high-speed expansion options such as PCIe 5.0 and multiple M.2 slots, and includes advanced connectivity like USB4, Wi-Fi 7, and 2.5 Gigabit LAN. The board features reinforced construction with ESD Guards, a steel backplate, and TUF Protection to ensure long-lasting performance.

Key Features

• Compatible with Ryzen 7000/8000/9000 Series processors
• Supports DDR5 RAM with speeds up to 4000 MHz (O.C.)
• Generous expansion options with PCIe 5.0 and multiple M.2 slots
• Equipped with Wi-Fi 7 and 2.5 Gigabit Ethernet for high-speed connectivity
• Built with durability features for long-lasting performance

Product Features

Powerful Connectivity Options

Includes 2.5 Gigabit Ethernet, Wi-Fi 7, USB4 ports, USB 3.2 Gen 2 and Gen 1 configurations for diverse peripherals and fast data transfer.

Robust Audio Capabilities

Realtek ALC1220P codec supports HD 8-channel audio, ensuring immersive audio for gaming and multimedia.

Efficient Cooling Design

Equipped with M.2 and VRM heatsinks for superior thermal performance and system stability under load.

Versatile Expansion Slots

Supports PCIe 5.0 x16 and multiple M.2 Key M slots for GPUs and fast SSDs.

User-Friendly BIOS Features

AMI BIOS with ASUS EZ Flash 3 enables simple updates and configuration for users of all levels.

Main Specification

• Product Description: ASUS TUF GAMING X870-PLUS WIFI - Motherboard - ATX - Socket AM5 - AMD X870
• Product Type: Motherboard - ATX
• Chipset Type: AMD X870
• Processor Socket: 1 x Socket AM5
• Compatible Processors: Ryzen 7000/8000/9000 Series
• Max RAM Size: 192 GB
• RAM Supported: 4 DIMM slots - DDR5, On-die ECC, Non-ECC, ECC, Unbuffered
• Storage Ports: 2 x SATA-600 (RAID), 4 x M.2
• USB / FireWire Ports: 2 x USB4, 3 x USB 3.2 Gen 2, 4 x USB 3.2 Gen 1, 1 x USB 2.0 (rear) + (1 x USB-C 3.2 Gen 2x2, 2 x USB 3.2 Gen 1, 4 x USB 2.0 via headers)
• Audio: HD Audio (8-channel)
• LAN: 802.11a/b/g/n/ac/ax/be (Wi-Fi 7), 2.5 Gigabit Ethernet, Bluetooth 5.4

Extended Specification

General

• Product Type: Motherboard - ATX
• Chipset Type: AMD X870
• Processor Socket: Socket AM5
• Max Processors Qty: 1
• Compatible Processors: Ryzen 7000/8000/9000 Series

Expansion / Connectivity

Expansion Slots

• 1 x CPU
• 4 x DIMM 288-pin
• 1 x PCIe 5.0 x16
• 1 x PCIe 4.0 x16 (x4 mode)
• 3 x M.2 socket (2280 M.2 Key M slot)
• 1 x M.2 socket (2242/2260/2280/22110 M.2 Key M slot)

Storage Interfaces

• 2 x SATA-600 - RAID 0 / RAID 1
• 2 x M.2 (PCIe 5.0) - RAID 0 / RAID 1 / RAID 10 / RAID 5
• 2 x M.2 (PCIe 4.0) - RAID 0 / RAID 1 / RAID 10 / RAID 5

RAID Features

• AMD RAID Xpert2 Technology

Interfaces

• 1 x HDMI
• 2 x Aerial
• 2 x Thunderbolt 4/DisplayPort/USB4
• 3 x USB-C 3.2 Gen 2
• 4 x USB 3.2 Gen 1
• 1 x USB 2.0
• 1 x LAN (2.5Gigabit Ethernet)
• 1 x Audio Line-in - Mini-jack
• 1 x Microphone - Mini-jack
• 1 x Audio Line-out - Mini-jack
• 1 x Audio Line-out (Center/Subwoofer) - Mini-jack
• 1 x Audio Line-out (Rear) - Mini-jack

Internal Interfaces

• 4 x USB 2.0 - Header
• 2 x USB 3.2 Gen 1 - Header
• 1 x USB-C 3.2 Gen 2x2 - Header
• 1 x Serial - Header
• 1 x Audio - Header

Power Connectors

• 24-pin Main Power Connector
• 2 x 8-pin ATX12V Connectors

Miscellaneous

• Included Accessories: 2 x M.2 rubber package, ASUS Wi-Fi Q-antenna, M.2 screw package, TUF GAMING sticker
• Cables Included: 2 x Serial ATA cable
• Software Included: Armoury Crate, ASUS AURA Creator, ASUS DriverHub, ASUS Fan Xpert 4, ASUS GlideX, ASUS TUF GAMING CPU-Z, DTS Audio Processing, Norton 360 for Gamers (60 days trial), TurboV Core, USB Wattage Watcher, WinRAR (40 days trial)
• Width: 30.5 cm
• Depth: 24.4 cm

Audio

• Type: HD Audio (8-channel)
• Audio Codec: Realtek ALC1220P
• Compliant Standards: High Definition Audio

Features

• BIOS Type: AMI
• BIOS Features: UEFI BIOS, ASUS EZ Flash 3, ASUS UEFI BIOS EZ Mode
• Sleep / Wake Up: Wake on LAN (WOL), Wake on PME
• Hardware Features: ASUS Enhanced Memory Profile (AEMP), CrashFree BIOS 3, Preboot eXecution Environment (PXE), TUF LANGuard, BIOS FlashBack button, ASUS Aura Sync, ASUS DIGI+ VRM, ASUS EZ DIY, ASUS Overvoltage Protection, ASUS ProCool, ASUS Q-Design, ASUS SafeDIMM, ASUS SafeSlot, ASUS Stainless Steel Back I/O, ASUS TUF Protection, BIOS FlashBack LED, ESD Guards, M.2 heatsink, M.2 Q-Latch, PCIe Slot Q-Release, pre-mounted I/O shield, Q-Antenna, Q-Dashboard, Q-DIMM, Q-LED, Q-Slot, VRM heatsink design, 16+2+1 Phase Power Design, AI Overclocking, AI Cooling II, AI Networking II, chipset heatsink, AMD Precision Boost Overdrive (PBO), 8 Layer PCB

LAN

• Network Interfaces: 802.11a/b/g/n/ac/ax/be (Wi-Fi 7), 2.5 Gigabit Ethernet, Bluetooth 5.4

Supported RAM

• Max Size: 192 GB
• Technology: DDR5
• Bus Clock: 4000 MHz (O.C.)
• Supported RAM Integrity Check: On-die ECC, Non-ECC, ECC
• Registered or Buffered: Unbuffered
• Features: Dual Channel Memory Architecture, AMD EXPO Technology

What’s in the Box?

• ASUS TUF GAMING X870-PLUS WIFI
• 2 x Serial ATA cable
• 2 x M.2 rubber package
• M.2 screw package
• TUF GAMING sticker
• ASUS Wi-Fi Q-antenna
